Manufacturer of Alu Alu Blister Packing Machine
Oral pills, capsules, hard and soft gelatine capsules, and other pharmaceutical products are perfectly packaged using Automatic Alu Alu Blister Packing Machines. Our blister packing machines go through a thorough quality assurance procedure to guarantee years of trouble-free service. Blister packs may be formed using either cold forming (ALU/ALU) or thermo forming (PVC/ALU) techniques, thanks to the machine’s special design that guarantees perfect timing between the two. The pharmaceutical business may make use of this machine’s capacity for mass manufacturing.
Blister packaging is ubiquitous in the retail industry and has found particular usage in the pharmaceutical industry. Blister packaging is preferable because it is aesthetically pleasing, allows for complete product visibility, and provides integrity assurance down to the single-dose level. Preformed plastic blisters may be attached to a cardboard or plastic backing, or they can be folded in half and heat sealed to create a clamshell blister.
Salient Features
- Packing Speed: 40 Cycles/min for Thermo-Forming. 35 Cycles/min for Cold-Forming.
- Feeding System: Auto feeding system by PLC Logic with pneumatic combination.
- Servo Drive Indexing: Servo web indexing by rigid PLC Logic.
- Operator Interface: User friendly HMI touch screen (Human machine interface).
- Pneumatic Operations: Festo make for fast response, oil free, minimum wear and tear, easy maintenance and universal availability of bought outs.
Packaging Materials
- Base Material: PVC / PVC-PVDC / ACCLAR / TRIPLEX / PP / ALU-ALU (OPA).
- Lidding Material: Aluminium with Heat Sealable Lacquer Coating.
Utilities Requirement
- Compressed Air: 16 CFM dry air having minimum pressure 6.0 kgs /cm2
- Water Cooler: 120 Litre/Hour. Temp. 15 ± 2 C
- Electrical Power: 6.5 KW, 415 V ± 10%, 3 Phase + N + E
- Earthing Cable: Copper, 2.5 mm2 (Minimum)
Technical Specification
Single Track Blister Packing Machine
| Specification | LI-Mech 1+ (Thermo Forming) | LI-Mech 1+ (Cold Forming) |
|---|---|---|
| Base Foil Width | PVC foil 150 mm | Alu-Alu foil 150 mm |
| Base Foil Thickness | PVC Foil 0.20-0.40 | Alu-Alu foil 0.13 – 0.15 |
| Base Foil Reel Diameter | PVC foil 440 mm | Alu-Alu foil diameter 440 mm |
| Sealing Foil Width | 146 mm | 146 mm |
| Sealing Foil Thickness | 0.025-0.035 mm | 0.025-0.035 mm |
| Sealing Foil Diameter | 210 mm | 210 mm |
| Max. Packet Forming Area | 85 x 150 mm | 85 x 150 mm |
| Output | Up to 30/Packs/Min. | Up to 30 Packs/Min. |
| Net Weight | Approx. 1050 Kgs. | Approx. 1050 Kgs. |
| Gross Weight | 1500 Kgs. Approx. | 1500 Kgs. Approx. |
Double Track Blister Packing Machine
| Specification | Cold Form ALU-ALU | Thermo Forming (When fitted) |
|---|---|---|
| Base Film Width | Alu. Foil 225 mm | PVC Film 225 mm |
| Blister Foil Thickness | Alu. 0.13 – 0.15 mm | PVC 0.20 – 0.40 mm |
| Reel Diameter | Alu. 440 mm | PVC 440 mm |
| Sealing Foil Thickness | 0.02 – 0.04 mm | 0.02 – 0.04 mm |
| Sealing Foil Width | 225 mm | 225 mm |
| Pack Length | 215 mm | 215 mm |
| Pack Width | 140 mm | 140 mm |
| Forming Depth | 12 mm | 12 mm |
| Machine Speed | 35 Cycles / Min | 40 Cycles / Min |
| Overall Dimension | 2900 (L) x 1180 (W) x 1915 (H) mm ±2% | |
| Net Weight Approx. | 1950 Kilograms | |
