Jacketed Mixing Vessel
Manufacturer of Jacketed Mixing Vessel
A Jacketed Mixing Vessel, featuring a Jacketed steam boiler, is employed for the blending of liquids and slightly solid materials. Assembly of a jacketed mixer showcasing various paddle blade types, such as pitched or flat blades with appropriate design. In the Mixer, two neighboring blades function in opposite directions, leading to a smooth thinning of the material and encouraging uniform mixing. Paddle-type blades are attached to scrapping arms and welded onto a hollow shaft, equipped with a separate drive system. A pivot is positioned at the lower support of the shaft to guarantee stability throughout rotations. Blades connected to the inner rod create motion of the substance. Different kinds of valves can be offered for material discharge based on user requirements.
Salient Features
- All contact components are constructed from Stainless Steel 304/316/316L materials.
- Offered in sizes from 10 liters to 20000 liters.
- Available in both Standard model and vacuum rated model.
- A heated jacket can be provided for warmth solutions.
- The height for discharge can be provided according to the user’s specifications.
- Equipped with a castor wheel and handle for effortless transportation of equipment.
- Sturdy legs eliminate the requirement for a foundation structure on the user’s part.
- An optional flush bottom ball valve is available to reduce residual effectively.
- Both standard and flameproof/explosion proof motors are available.
- Customized RPM options are available to meet specific process needs.
- An optional Graphical User Interface can be provided for the PLC system.
Applications
- Herbal Shampoo manufacturing
- Liquid Soap manufacturing
- Hand Wash manufacturing
- Sanitizer manufacturing
- Dish Wash manufacturing
- Laundry Soap manufacturing
- Emulsion manufacturing
- Liquid Gel/Ultrasound Gel manufacturing
- Syrup, Suspensions and Oral Liquid Gel manufacturing
- Paint, Coating & Chemicals manufacturing
Technical Specification
| Description | Specification |
|---|---|
| Capacity | 5 Liters to 50000 Liters |
| Power Supply | 0.5 H. P. to 100 H. P. |
| Power Voltage | 440 volts, 3 phase, 50 hertz |
| Gearbox | Helical type / similar |
| Stirrer Type | Pitch/Paddle/Hydofoil/Anchor type Stirrer |
| Stirrer MOC | Stainless Steel 304/316/316L |
| Stirrer RPM | Suitable RPM based on process requirements |
| Stirrer Mounting Orientation | Top Mounted or Bottom Mounted |
| No. of blades | Two |
| Shaft Diameter | Suitable Diameter |
