R&D Pilot Lab Multi Mill
Manufacturer of R&D Pilot Lab Multi Mill
The Lab Multi Mill efficiently handles a diverse array of wet and dry materials through granulation, pulverization, mixing, shredding, and chopping, all without requiring any extra specialized accessories. The device regulates the size reduction process by utilizing the concept of adjustable power swing hammer blades, featuring both knife and impact edges that rotate alongside a carefully selected screen. In contrast, none of the methods—grinding, compression, impact, or shearing—achieve controlled size reduction; these represent the four standard principles of reduction. Size can only be reduced in a controlled manner through shearing, unlike the other three methods.
The vertical rotor machine has streamlined the material flow process. As the material enters the chamber for processing, it moves towards the chamber’s edge and flows through the screen in both tangential and radial directions, ensuring that it does not become clogged or overheat.
Process Operation
To achieve the necessary level of particle size reduction, a Multi Mill operates on the principle of variable-force swing beaters equipped with knife and impact edges that rotate within a selected screen. The material is introduced into the hopper, which subsequently directs it into the processing chamber. Upon reaching the chamber’s edge, the material moves through the screen in both radial and tangential directions. Finally, the treated material is collected in the container located beneath the processing chamber.
Unique Features
- Machine portable on castor wheels
- High output with process uniformity
- Blades and scrapers are made of hard materials and plated with hard chrome
- Direction of the blade rotation can be changed using a reversing switch for hammer or knife operation
- Multiple combinations of Screens / Speeds / Number of Blades
- Direction of blade rotation for every product type
- High screen opening area for higher throughput
- Easy dismantling and cleaning of all components, reducing downtime
Technical Specification
| Model No. | LI-MM 50 |
|---|---|
| Output | Up to 50Kg per hour |
| No of Blade Knifes | 08 Nos |
| MOC | SS316 / SS304 |
| Motor | 1HP |
| Power Voltage | 440V, 3 Phase, 50Hz |
| Mobility | tdrough castor wheels |
| Sieve Size | 0.5mm to 12mm as per requirements |
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
