R&D Pilot Lab V Cone Blender

Process Operation

The ingredients are placed into the blender. The suggested fill-up volume for the V-Blender ranges from 50 to 60% of its total capacity. During rotation, a motion of tumbling takes place. As the V-Blender rotates, the material separates and merges in an ongoing cycle. The continuous back-and-forth motion between the substance and the mixer leads to a uniform mixture. The product is gathered from the base of V using a butterfly valve. Typical blending durations usually fall between 5 to 15 minutes, influenced by the characteristics of the material being mixed.

Special Features

• Rotating V type shell with large capacity.
• Intensifier bar for special applications available.
• Easy loading & unloading of material.
• Dust-free operations when combined with Bin charging system.
• Special baffles to increase mixing shear.
• Near complete discharge of product material, integrated vacuum loading option available.
• SS 316 material is used for construction.
• No shaft projection, hence no product contamination.
• Easy to clean with internal attachments like lump breakers and liquid dispensers.
• Ideal for blending dry powders and granules, including fragile material.
• Designed for dust-free processing, complete discharge of material with no contamination.
• Minimum maintenance required.

Technical Specification

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
 * Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
