Semi Automatic Capping Machine
Manufacturer of Semi Automatic Capping Machine
The Semi-Automatic Capping Machine/semi-automatic cap sealing machine is convenient to transport and simple to use. We provide a semi-automatic capping machine featuring a motor, enabling the operator to manually align bottles beneath the capping head. The cap-tightening mechanism includes a well-designed cam that allows the head to continuously move up and down while rotating around its axis. A device equipped with a capping head fastens caps in place and turns them with consistent torque, using either a spring or a magnetic torque controller. The adjustable frequencies system allows for customized capping head speeds.
Unique Features
- Machine design that is both portable and versatile.
- Stainless steel 304 used for machine building.
- Compatible with all variations of plastic screw caps, ROPP aluminium caps, and PP caps.
- Structure of a Powerful Machine.
- Using less energy and producing less noise.
- The gauge may be adjusted to accommodate bottles of varying heights.
Technical Specification
| Specification | Details |
|---|---|
| Product Diameter | 25 mm to 85 mm* |
| Capping Type | Screw/ROPP |
| No. of Head | Single |
| Product Height | 150mm* |
| Power | 1.0 H.P. |
| Electrical | 415V, 3 Phase, 50Hz |
| Speed | Max. 30 BPM |
| Overall Dimension | 995 mm x 710 mm x 1350 mm |
| Net Weight | 180 Kilograms |
| Gross Weight | 275 Kilograms |
*Specification can be changed as per customer’s requirements
*More Higher Capacities Machine Models available on specific request of customer
