Semi Automatic Capsule Counting and Filling Machine

Working Principal

A thing A variety of delivery chutes are available to accommodate different container sizes, and they transport products from the counting disc into filler tubes. A unique machine with a dust-free passage system is integrated with the filler and located beneath the hopper. It is designed to count and fill large quantities of pills or capsules into plastic or glass bottles. The anticipated fill capacity is provided by the counting disc. No matter if the tablet is hard or soft, coated or uncoated, every disc is meticulously made to fit. A single-track filler can fill one bottle at a time, but a set of four machines can fill four bottles at once, greatly increasing production. The rpm varies in relation to the containers and stocks. To make sure the disc works smoothly and efficiently when counting uncoated tablets, it has a special Dust Extractor system that takes dust out of the way on the way to the container.

Advantages

• Single manual operator.
• To Count 1 to 1000 capsules/Tablets.
• Specific dust extractor to remove dust particles.
• Designed to precisely count and pack capsules and tablets of any size.

Salient Features

• Each disc is custom designed and manufactured to meet customer’s needs.
• The machine is provided with adjustable filler which can be elevated from 20 to 25 degrees, to facilitate entry of the products into the disc holes.
• The machine is fitted with superior quality delivery chutes which direct the product from the counting disc into the stainless-steel filler tubes of various sizes, to suit different containers, suitable to work on 3 phase ac, 1 HP motor, 1440 rpm with variable speed drive.
• The entire machine is mounted on MS body.
• Simple operation, only one operator required, and operating training can be done in 10 min.
• The machine is provided with one countable type disc.
• G.M.P. model: M.S. body of the machine cladded with SS sheet.

Technical Specification
