Manufacturer of Semi-Automatic Cosmetic Tube Filling Sealing Crimping Machine
Streamline your packaging process with the help of a cosmetic tube filler machine. Rapid production is possible with the Semi-Automatic Cosmetic Tube Filling Closing Machine because of its high throughput and maintenance-free operation. The amount that is dispensed into each tube can be adjusted. Whether a batch is filled by hand or by machine, the result is the same. Workers are less likely to sustain injuries on the job when they are not directly in charge of operating machinery. Additionally, the machines lessen the monetary toll of these disasters. This multi-purpose tool can clean, fill, seal, and label tubes, among its many other uses. The end result is an increase in overall production efficiency.
The machine initially fills the tubes up to a specific height. Once filled to capacity, it promptly seals to avoid waste and leaks. There are a few different approaches to filling makeup tubes. Different manufacturers have vastly different levels of automation or human intervention in their tube filling machines.
Unique Features
- Tube-feeding, by Hand
- Compact rotary type design
- Capacity from 5 grams to 50 grams
- Accuracy of filling 1%
- Appropriate and consistent stuffing
- 0 Tube Inadequate Filling System
- Pneumatic cylinder for tube sealing, coding, and cutting
- Leister’s heater and blower make up a hot air system used for tube sealing.
- You can also get a batch coding number based on your gender.
- A water pump is used to cool the tube from the outside, which results in better sealing.
- Converting between Combo Models is a breeze.
- After the filling time, there were no tails.
- Depending on your needs, we can make all of the moving parts out of stainless steel (SUS).
- The number of tubes that have been filled can be seen on a production counter shown on the control panel.
- Reduced need for upkeep
- Tubes are ejected automatically.
- All pneumatic “Janatics,” “Festo,” and “Spac” components
Extras, if needed
- Jacketed Hopper with Stirrer
- Automatic Tube Orientation System
- Extra Size Syringe Set
- Air Compressor
Technical Specification
| Specification | Details |
|---|---|
| No. of Filling Heads | Single |
| No. of Stations | 8 |
| Production Output (Per Min) | 25 – 30 tubes |
| Tube Diameter | 12 to 50 mm |
| Tube Length | 50 to 200 mm |
| Tube Loading System | Manual |
| Tube Orientation | Manual |
| Filling Range | 3 gm to 250 gm |
| Compressed Air Required | 6 CFM |
| Power Consumption | 1.5 H.P. |
| Electric Characteristic | 440V, 3 Phase, 50Hz, 4 Wire System |
| Net Weight | 250 Kgs. |
| Gross Weight | 375 Kgs. |
* Specification can be changed as per customers’ requirements
