Shrink Sleeve Label Applicators & Tunnels
Manufacturer of Shrink Sleeve Label Applicators & Tunnels
Our state-of-the-art shrink sleeve applicator is a modern machine that improves the visual appeal of containers of all shapes and sizes with eye-catching container labelling. Our shrink sleeve applicator allows for the application of full body, half body, or neck sleeves using interchangeable parts, resulting in an attractive appearance for your products.
To optimize efficiency, you have the option to choose either an electric heat tunnel or a steam tunnel depending on the unique characteristics of your containers, such as their shape, size, and output.
Salient Features
- High-speed shrink sleeve applicator that sleeves maximum 100/200/300 units/minute.
- Servo motor-controlled film feeding.
- VFD for conveyor and machine speed control.
- No Bottle, No Sleeve interlock.
- PLC controlled operations.
- Touch screen HMI with detailed diagnostics for fault finding.
- Unwinder for smooth film feeding.
- Quick changeover – Few change parts.
- Option: Steam Tunnel / Shrink Tunnel.
- Option: Pre-Heating Tunnels.
Technical Specification
| Specification | Details |
|---|---|
| Machine Dimension | 2100 mm (L) x 850 mm (W) x 2000 mm (H) |
| Weight | 400 Kgs. Approx. |
| Main Input Power Supply | 230 Volts / Single Phase + Neutral / AC |
| Power Consumption | 1.5 KW |
| Speed | Up to 400 BPM |
| Bottle Diameter Range | 28 mm to 125 mm |
| Bottle Height Range | 50 mm to 280 mm |
| Sleeve Thickness | 0.03 mm to 0.08 mm |
| Sleeve Roll Diameter | 300 mm to 400 mm |
| Sleeve Roll Core Diameter | 76 mm (3 Inches) |
| Material of Construction | |
| Main Body | S.S. 304 |
| Sleeve Mandrill | UHMW / Nylon |
| Feed Worm Mounting Unit | Anodized Aluminium |
| Bottle Carrying Unit | Anodized Aluminium |
| All Shafts | Mild Steel EN 8 Zinc Plated |
| Sleeve Pulling Roller | Special Rubber |
| Sleeve Inserting Roller | Special Rubber |
| Automation | |
| PLC | Delta / Mitsubishi |
| HMI / MMI | Delta / Mitsubishi – 7” |
| Servo Motor | Panasonic / Mitsubishi |
| Servo Driver | Panasonic / Mitsubishi |
| AC Frequency Drive | Delta / Mitsubishi |
| Sensors | Leuze / Panasonic / Sick / Optex |
| Contactor | Telemecanique / Schneider |
Versatile Applications Across Industries
The applications of our versatile Shrink Sleeve Applicator Machine span across various industries, including pharmaceuticals, food and beverages, cosmetics, agrochemicals, distilleries, breweries, household products, and lubricants.
Its efficient labelling capabilities cover containers, bottles, jars, cans, and cartons of all shapes, ensuring precise and attractive packaging for your diverse range of products.
Transform your product packaging and make a lasting impression with our automatic shrink sleeve label inserter machine. Elevate your packaging today.
