Single Head Linear Tube Filling Machine
Manufacturer of Single Head Linear Tube Filling Machine
Robust design and solid manufacturing techniques provide the greatest package quality and maximum efficiency with little maintenance. Our expertise provides Single Head Linear Tube Filling Machine for cosmetics, pharmaceuticals, chemicals, and food sectors. Filling and sealing Aluminum/Lami/PVC tunes is possible with the equipment. Lodha is the top pharmaceutical and cosmetic tube filling machine linear type manufacturer and exporter. The tube filling machine meets global safety requirements. This machine uses high-quality components and innovative technology to fill and seal plastic, metal plastic laminate, and aluminum laminate tubes up to 60 tubes per minute. We Manufacture & sale this Linear Tube Filling Machine at competitive prices.
Unique Features
- Sealing and filling plastic or laminated tubes.
- Panel Display with Color Touch Screen by Schneider. PLC Control System by Schneider.
- Control the rate of production with a variable-speed converter.
- Tubes can be loaded, washed, positioned, filled, sealed, and ejected automatically.
- Pneumatics are used for both tube loading and tube washing.
- Design that is rugged, long-lasting, user-friendly, and low-maintenance.
- BANNER’s Photoelectric Tube Positioning Sensor determines where the tube is placed.
- Filling in many colors at once is an option.
- Complete with Climate Control and Independent Cooling System.
- In the absence of a tube, an alarm will sound. Filling from the bottom up with a closed nozzle guarantees a precise and sanitary fill every time.
- Tool-free maintenance and polishing.
- Protective measures against production overload and unsafe conditions are included.
- Automatically detecting a tube that has been turned upside down is possible.
- All material-contacting parts are constructed from high-grade 316L stainless steel in accordance with cGMP regulations.
- Our tube filler can be customized with a double-jacketed temperature-controlled hopper and agitator.
Technical Specification
| Filling Range | 5 gms to 200 gms |
|---|---|
| Output per Minute | Up to 60 Tubes/ Min. |
| Machine Construction (All Contact Parts) | Stainless Steel 316 |
| Hopper | 60 Kg capacity (Working Volume 50 Kg) |
| Filling Volume Setting | Cam for Valve operation, Fine-Tuning Adjustable Control System |
| No Tube – No Fill Device | Activate Sensor with Electrical Logic Control system |
| Filling Accuracy | ± 1% |
| Indexing Device | Indexer Manifold |
| Auto Tube in Feeder | Cassette Device System with Four Cassettes (One Tube Size will be provided) |
| Change Parts | Syringe Pump Housing (30gms to 100 gms), Two Cassettes, Tilting Cam, Feeding Con, Holder, Filling Nozzle, and Heating Adopter (Removable type for one-size tubes) |
| Tube Orientation Device | Top Drive (Photocell Unit), Stepper Motor, ‘I’ Mark Sensor (DETALOGIC Make) at Separate Station |
| Lami/Plastic Tube Heating Device | LEISTER or BAK Swiss Make, with Blower 0.35 HP, BLOWTECH Make, Hot Air Tool Adopter, Jacketed Water-Cooling System at Separate Station |
| Lami/Plastic Tube Sealing Device | Pneumatic operated, Jacketed Water-Cooling System, Sealing & Coding, Tube is Pressed, Sealed, Batch Coded, Metal Stereos Coding Letter Punch (Female type 0-9, one set) at Separate Station |
| Trimming Device | Pneumatic operated at Separate Station |
| Tube Ejection | Automatic Filled Tube Ejection at Separate Station |
| Machine System Description | Empty Tube Feeding, ‘I’ Mark Orientation, Filling, Sealing, Crimping, Coding, and Filled Tube Ejector Automatically |
| Machine Security | Overload Clutch for Centering and Micro Switch Cut-off System |
| Control Panel | Emergency Stop, Re-set, Inching, User Friendly, Electrical Logic System with Interlock & Indication on Panel |
| Motor | 1.5 HP; 1440 RPM; 3 Ph.; 440V AC; Hindustan Make |
| Gear Box | Suitable Gear Box Ratio 30-1; PREMIUM Make with Separate Drive |
| Production Speed Control | Variable Speed Control with Suitable VFD Drive; DELTA Make |
| Production Counter | Activate Sensor with Electrical Logic Display (6 mm, 6 Digital Counter) |
| All Pneumatic Components | FESTO Germany Make |
| Machine Entire Frame | Fabricated in Mild Steel with Powder Coated & Hard Chrome Plated & ENP Coated, All Other Cams and Levers in Graded Casting & Alloy Steel, Side Covers in SS-304 |
| Power Input | 2-5 kW, 3 Ph. |
| Machine Dimensions | (L) 2640mm x (W) 1080mm x (H) 2450mm |
| Net Weight | Approx. 1200 Kgs |
