Eye Drop Filling Plugging Machine

Process Operation

The primary purpose is to fill the bottle before closing it with the plug and the screw cap. moving containers are fed onto an SS slat conveyor and then transferred to a star wheel that uses an indexing mechanism to rotate clockwise, picking up the containers and delivering them to a filling station with diving-type filling nozzles. The filled container spins and transports the bottle to the nozzle placing station, where the nozzle is oriented by a vibratory feeder before being picked up by a vacuum pickup system, rotated by 180 degrees, and placed on the bottle. The bottle is then transferred by star wheel to the next station, where the cap is similarly oriented before being picked up by a vacuum pickup system and taken to the screw capping station.

Salient Features

• One machine that can do everything from filling to sealing to capping or ROPP capping automatically.
• Minimalist and straightforward layout.
• Cladding and framework are both made of SS 304 and have a beautiful matt finish.
• The first of its kind for filling tiny quantities of eye, ear, and nasal drops.
• Insertion and pushing of the inner plug via pneumatics.
• Installing a pneumatic cap.
• All metal components are SS 316.
• There’s no filling the bottle if there’s no bottle. The cap-less, bottle-less bottle system.
• Protects indexing mechanism with a torque restriction.
• Modular nitrogen purge system.

Technical Specification
