R&D Pilot Lab Fluid Bed Dryer
Manufacturer of R&D Pilot Lab Fluid Bed Dryer
The Fluid Bed Dryer provides the two great benefits of efficiency and product homogeneity that are often associated with fluid bed dryers. In this method, a fluidized bed is used to create droplets of a liquid binder by atomizing the solution with high-pressure air. Granule size is increased as a result of these droplets forming liquid bridges between the individual particles. One advantage of this approach is that it can finish two distinct unit operations in one processing step. Methods like drying and granulating are part of these procedures. A combination of fluid bed action and microprocessor control over airflow, input air temperature, and drying duration yields final samples and batches that are extremely repeatable. The technology’s end result, granules, are highly soluble and exceptionally porous, two characteristics that have several uses in the food, pharmaceutical, and chemical industries around the globe.
Process Operation
As a first step, hot air is forced through the material as it is being fed onto the trembling steel bed. By coming into contact with each particle in the material bed, the high-pressure hot air flow fluidizes the bed. For materials that are particularly sticky or wet, the dryer’s ability to regulate the airflow along its length allows for optimal fluidization. The material will gradually lose moisture as it passes through, until it reaches the desired dryness. Upon reaching the required level of dryness, the material is transferred to a cooling zone. This step involves exchanging the hot air for the cold air that brought the temperature down to the desired level.
Special Features
Technical Specification
- Use for both drying and granulating processes.
- Use of high-retention polyester filter cartridges.
- Repeated cartridge filter cleaning by compressed air counterblows while drying or granulation processes keep taking place.
- Easy and quick filter disassembling.
- Sample thief.
- Inspection windows.
- Inlet air temperature probe.
- Product temperature probe.
- Main structure in round tubular.
- Automatic management by PLC, touch screen operator panel, and panel printer.
- Air Treatment Unit equipped with inlet/outlet Hepa filters and steam heating battery.
- Intelligent process control and safety interlock by PLC & Colour Touch Screen MMI along with printing, 21CFR part 11 and SCADA compatibility.
| Technical Description | LI-FBD1 | LI-FBD5 | LI-FBD10 |
|---|---|---|---|
| Working Capacity (Kgs.) | 1 | 5 | 10 |
| Blower Motor HP | 2 | 3 | 3 |
| CFM | 500 | 700 | 700 |
| Steam Consumption kg/hr @ 3 kg cm pressure | NA | NA | 15 |
| Heaters (KW) | 3 | 3 | 6 |
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
