R&D Pilot Lab Starch Paste Kettle

Design Mechanism

One of the applications involves producing starch-based paste in the Paste Kettle.
A container with a dome-like shape guarantees even heating of the starch paste while maximizing the surface area it covers. The design, featuring a tilting mechanism, facilitates the effortless transfer of the paste into another container or vessel. The starch is added to the kettle, followed by water, until the mixture achieves the preferred consistency. A lid is set on the kettle, and it is subsequently heated until the starch fully dissolves, resulting in a thick paste. This paste can be mixed by hand, or you can utilize an anchor-type agitator that will keep the paste moving continuously to avoid any lumps from developing. No matter what, the outcome will be the same. The temperature can be set to the exact degree you want by using the provided thermostat, and you can check the temperature on the included dial thermometer. The jacket can be customized to suit a range of different operating temperatures.

Features

The Paste Kettle complies with cGMP standards and features a jacketed hemispherical bowl along with all necessary steam accessories.

• Contact parts constructed from stainless steel 316/316L.
• Bottom discharge is achieved by the use of a flush bottom ball valve.
• Mechanical tilting using a worm and worm wheel configuration.
• Optional motorised driving system for tilting.
• Agitator detachable with Anchor blades and Teflon scrappers.
• Optional hydraulic lifting and lowering setup.
• Lab Model Paste Kettle comes with 25 Litters capacity.

Unique Features

• According to GMP standards, all contact parts are constructed of SS 316.
• Hemispherical shape for efficient paste mixing.
• The jacket is equipped with a steam/thermic/fluid heating system.
• Top-mounted motor and gearbox assembly provides power.
• A kettle tilting system is provided for starch paste outflow.
• Heater insulation is installed to prevent heat loss.
• Design of an anchor type impeller for proper paste mixing.
• System of safe earthing.
• Sizes range from 10 to 250 litres.

Technical Specification

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
