Syrup Bottle Ropp Capping Machine
Manufacturer of Syrup Bottle Ropp Capping Machine
The Syrup Bottle Ropp Capping Machine for Syrup Glass Bottles showcases exceptional versatility and efficiency, serving a wide array of sectors such as food, pharmaceuticals, herbal products, and liquor. This machine is crafted to address the specific capping requirements of various bottles, including those for syrup, food, food color, pharmaceuticals, herbal hair oil, and liquor, ensuring exceptional performance and dependability. The versatile qualities of this material establish it as an essential element in the packaging workflow for producers aiming to uphold product quality and enhance efficiency in their operations.
Process Operation
The filled bottles fed on feeding conveyor through back pressure of the liquid filling machine conveyor and fed into an in-feed star wheel by in-feed worm. While moving in feed star wheel, bottles pick up caps one by one from delivery chute. The descending rotary sealing one heads hold bottle’s neck with desired pressure. The sealing is done in a programmed roll-on manner, accurate positioned of the caps is done mechanically by means of a rotating unscramble, to direct the caps correctly into the chute, when the chute is filled up the rotating unscramble drive is disengaged, hence, there is no chance to damage of caps. The sealing roller takes place due to rotating sealing head and transfer movement of sealing & threading rollers due to sealing cam. The sealed bottles are discharged by exist star wheel on conveyors.
Salient Features
- No Bottle – No Cap” System
- No Cap – Machine Stop System
- Machine construction in Stainless Steel Finish
- Infeed and Exit Star Wheel with Overload Clutch System to avoid Bottle breakage
- Single Drive Synchronizing Total Operation of Star Wheel and Turret with Star Wheel
- Cap Feeder with Variable Speed System for feeding control of caps.
- Minimum Change Over and Setting time
- Hopper can be completely dismantled for easy cleaning
- Various safety features including Clutch system to avoid Bottle Breakage
- Single Drive synchronizing operation of Conveyor and Star Wheel
- Minimum Change over time
Technical Specification
| Model No. | LI-BCS 1R | LI-BCS 4R | LI-BCS 8R | |||
|---|---|---|---|---|---|---|
| Bottle Diameter | Up to 85mm* or other shape bottle with proper base | |||||
| Bottle Height | 150 mm* | 300 mm* | 300 mm* | |||
| ROPP Cap Size | Up to 38 mm* | Up to 38 mm* | Up to 38 mm* | |||
| Electrical | 415VAC 3Phase and 220 VAC Single Phase Power Supply (50 Hz) with A.C. Drive | |||||
| Power | 1.0 H.P. | 2.0 H.P. | 3.0 H.P. | |||
| Conveyor Height | 815-850 mm | 800-900 mm | 850-900 mm | |||
| Overall Dimensions | 1500 mm (L) x 735 mm (W) x 1800 mm (H) | 1500 mm (L) x 1000 mm (W) x 2000 mm (H) | 2000 mm (L) x 1050 mm (W) x 2000 mm (H) | |||
| Production Speed | Up to 60 BPM | Up to 100 BPM | Up to 200 BPM | |||
* Specification can be changed as per customer’s requirements
* More Higher Capacities Machine Models available on specific request of customer
