Ribbon Blender

Process Operation

A helical ribbon agitator and a horizontal trough with a central shaft make up a ribbon blender. Two opposing ribbons are installed on the same shaft in this blender. In one direction, the ribbons move the solids slowly, and in the other direction, they move the solids quickly. The solids are charged, mixed, and discharged from the bottom of batch-operated ribbon blenders. The turbulence created by opposing ribbons causes mixing in addition to the solids’ movement through the trough.

Special Features

• Available in two shapes – U & W
• U-for Low to Medium Volume Capacity (single shaft)
• W-for Large to Mega Volume Capacity (double shaft)
• Batch size based on 65% of Blender volume
• All contact parts in stainless steel 304
• Bearing mounted on lanterns out of mixing zone to avoid Cross contamination
• Feeding through a charging port mounted on top of the blender
• Reduced Material handling due to side discharge facility of processed materials
• Monoblock Design avoids Cross Contamination
• Meets all cGMP / cGMP standards
• Air purge on the side entry seals for better cross contamination control
• Continuous Ribbon design for complete discharge of the finished product
• Variable frequency drive for fine tuning the Shear energy at different stages of Blending
• Belt driven power transmission for Quieter environment and less maintenance
• Reduced material handling with Top mounted charging port and Side discharge arrangement for Total containment
• Bearing mounted on the lanterns outside the Mixing zone to avoid Cross contamination
• Paddle style agitator instead of Ribbon for Blending fragile materials
• Capacity available 50 Kg to 2500 Kg

Technical Specification
